Data Format (csv file)
1st line
| Column | Units | Comments |
|---|---|---|
| 1 | YYYY/MM/DD | Launching Date |
| 2 | hh:mm:ss | Launching Local Time |
| 3 | hour | Time Zone (GMT+??) |
| 4 | Degree | Latitude |
| 5 | Degree | Longitude |
| 6 | m | Sea Level |
| 7 | Sonde Serial No. |
below 2nd line
| Column | Units | Comments |
|---|---|---|
| 1 | min | Elapsed time from launch |
| 2 | m | Height (above sea-level) |
| 3 | hPa | Pressure |
| 4 | Degree C | Temperature |
| 5 | % | Relative humidity |
| 6 | m/s | Zonal wind |
| 7 | m/s | Meridional wind |
Data Format (snd file)
| Column | Units | Comments |
|---|---|---|
| 1 | km | Height (above sea-level) |
| 2 | hPa | Pressure |
| 3 | Degree C | Temperature |
| 4 | % | Relative humidity |
| 5 | m/s | Vertical velocity estimated from ascending speed |
| 6 | (km) | Height corresponding to the vertical velocity |
