Boundary Layer Radar (BLR) / Lower Troposphere Radar (LTR) / LQ7
Observation Data


(Version 02.0212)


Please note: If you acquire Shigaraki-BLR/LTR data, we ask that you acknowledge us in your use of the data. This may be done by including text such as Shigaraki-BLR/LTR/LQ7 data provided by Research Institute for Sustainable Humanosphere of Kyoto University. We would also appreciate receiving a copy of the relevant publications. Thank you!
This data has been registered in IUGONET (Inter-university Upper atmosphere Global Observation NETwork) metadata database. The IUGONET metadata database will be of great help to researchers in efficiently finding and obtaining ground-based observation data spread over the institutes/universities. Click and visit to the IUGONET website.

IUGONET also prepared the iUgonet Data Analysis Software (UDAS) for the upper atmospheric observation data. If you install the UDAS, you can easily access, download, visualize and analyze the MU radar observation data through the Internet. Please click and try to use the UDAS.


Archive parameters:
CSV (Comma Separated Values) formatted data are available.
File names of CSV data are composed of date and variable abbreviations: (year)(month)(day).(variable).csv
Latest ASCII data is also available.

Variables File Units Comments
Zonal wind uwnd m/s Westerly wind is positive
Meridional wind vwnd m/s Southerly wind is positive
Vertical wind wwnd m/s Upflow is positive
Echo intensity for Beam 1 pwr1 dB Arbitrary unit
Echo intensity for Beam 2 pwr2 dB Arbitrary unit
Echo intensity for Beam 3 pwr3 dB Arbitrary unit
Echo intensity for Beam 4 pwr4 dB Arbitrary unit
Echo intensity for Beam 5 pwr5 dB Arbitrary unit
Spectral width for Beam 1 wdt1 m/s Half power full width
Spectral width for Beam 2 wdt2 m/s Half power full width
Spectral width for Beam 3 wdt3 m/s Half power full width
Spectral width for Beam 4 wdt4 m/s Half power full width
Spectral width for Beam 5 wdt5 m/s Half power full width

Beam Direction
In 1992 2000- 2006.03.30-
Beam No. (Az, Ze) (Az, Ze) (Az, Ze)
1 ( 0, 0) ( 0, 0) ( 0, 0)
2 ( 0, 15) ( 0, 9.8) ( 0, 14.2)
3 ( 90, 15) (180, 9.8) ( 90, 14.2)
4 - (90, 9.8) (180, 14.2)
5 - (270, 9.8) (270, 14.2)
The antenna beam is switched every FFT.

Data Format

Observation Parameters
Parameter In 1992 2000.01.01-06.23 2000.06.24-2004.06.14, 2005.02.25-2006.03.29 2004.06.18-2004.11.01 2006.03.30-
Pulse length 1 micro sec 1.33 micro sec 1 micro sec 0.67 micro sec 0.67 micro sec
Sampling interval 0.67 micro sec 1.33 micro sec 1.00 micro sec 0.67 micro sec 0.67 micro sec
Inter Pulse Period 50 micro sec 100 micro sec 100 micro sec 100 micro sec 100 micro sec
Number of coherent integrations 64 32 32 32 64
Number of incoherent integrations 32 30 30 30 18
Number of FFT points 128 128 128 128 128
Pulse compression No 8 bit optimized code (*) 8 bit optimized code (*) 8 bit optimized code (*) 16 bit optimized code (*)
(*) Spano, E. and O. Ghebrebrhan, Sequences of complementary codes for the optimum decoding of truncated ranges and high sidelobe suppression factors for ST/MST radar systems, IEEE Transactions on Geoscience and Remote Sensing., 34, 330-345, 1996.
